3
1 Locate the diverter valve with the finger tight fittings of the inner tubing kit.
2 Unscrew the two finger-tight fittings of the inner tubing kit at the diverter
valve.
Liquid spills or fraction losses
Worn or damaged tubings can cause potential spills or lead to
fraction losses.
➔ Explicitly follow the described installation procedures to
maximize the lifetime of inlet / waste tubing assembly and the
valve to needle tubing, and to avoid potential spills or fraction
losses.
➔ Regularly inspect the tubings and exchange them if they are
worn out or show visible signs of damage.
Connect the tubings as described in order to maximize their lifetime
and operating security.
