1Getting Started
12 N1913/1914A Installation Guide
These keys are located along the lower edge of the display.
Key Function
Press this key to access general configuration-menus, such as GPIB
address. You can also access some measurement configuration-menus.
The measurement screen remains visible.
Press this key to access the channel configuration menus. Channel
parameters such as averaging and offsets are configured from this menu.
Press this key to access the triggering menu. The triggering feature will
be made available in future for power sensors with triggering capability.
Press this key to setup relative measurements or set display offsets.
Use this key to configure the selected measurement.
Press this key to access the measurement display menu. You can choose
the displayed measurement resolution, units and display format.
Use this key together with to configure measurement
displays.
