19
Instrument Memory & Volatility
Non-Volatile Memory
Disk Drive Partitioning
The instrument’s disk drive is divided at the factory into three visible partitions, labeled C:, D: and E:, plus a
fourth hidden partition.
Details of the sizes and functions of all partitions are provided in Ta b l e 5 - 2 below.
Table 5-2 Disk Drive Partitions
Partition
Label
Size (GBytes) Purpose
C: 32 GB Primary partition for applications and secondary
data.
D: 17 GB Default location for user data.
E: 2 GB Calibration data.
Hidden 23 GB Factory recovery image of the C: partition.
