N9310A RF Signal generator
Quick Start Guide 15
Some Help Hints
Refer to the following hints to set the signal generator to
your required setting:
• Set the screen saver on by pressing
> Screen Saver> On
• Select a display style by pressing
> Display Style
• Toggle the phase noise mode by pressing
> Opti. F Noise> Normal/ResFM Opt.
• Save the current configures for your frequent use to
either local memory or an external USB memory by
pressing
> Save
• Connect and set an external reference by pressing
> Ref Setups
• Connect an external display monitor to the VGA
connector for the education projects or other needs.
Utility
Utility
Utility
File
Utility
NOTE
The calibration cycle of N9310A RF Signal Generator is one year.
NOTE
A button cell provides power to the real time clock of the signal
generator. It is not rechargeable. If you find your N9310A encounters a
clock defect, please contact your nearest Agilent Customer Contact
Center (CCC) for service.
