Agilent Technologies N9310A Quick Start Guide

N9310A RF Signal generator
Quick Start Guide 11
Generating a Step Sweep Signal
To simplify the example, assume you wish to generate a RF
sweep signal with the characteristics of:
• Frequency range from 1 to 2 GHz
• 10 step point
• Dwell time of 500 ms for each step
Setting up a Step Sweep
Operation Notes
1. Press hardkey Sets the signal generator to its
factory-defined instrument state.
2. Press hardkey Enables the submenu of sweep
softkeys.
3. Press Step Sweep softkey Enables the submenu of sweep
settings.
4. Press RF Start > 1 > GHz Sets the step sweep start
frequency to 1 GHz.
5. Press RF Stop > 2 > GHz Sets the step sweep stop
frequency to 2 GHz.
6. Press #Points > 10 > Enter Sets the step point to 10 in the step
sweep.
7. Press
More>Step Dwell>500>ms
Sets the dwell time to 500 ms for
each point in the step sweep.
Preset
Sweep
