Agilent Technologies N9310A Quick Start Guide

6 Quick Start Guide
N9310A RF Signal Generator
The Rear Panel at a Glance
The signal generator rear panel provides input, output, and
remote interface connections. Refer to “Rear Panel Overview”
on
User’s Guide for more information.
VGA OUTPUT
DEV
TRIG IN
HOST
MOD IN
PULSE M OD I N
REF IN
REF OUT
I IN
1V RMS
MAX
Q IN
LINE:
100-240V
50-60Hz
100W M AX
Made in China
HIPOT PASS
N931 0A N93 10A-CFG00 2
SER:CN*********
1
3
4
6
7
8
9
10
11
12
2
5
1 AC power switch 7 Pulse input connector
2 AC power connector 8 Modulation source input connector
3 USB host connector 9 Q input connector
4 Trigger input connector 10 I input connector
5 Reference output connector 11 VGA connector
6 Reference input connector 12 USB device connectors
