Replaceable Parts
Hardware and Other Instrument Parts
3-48
Main Chassis and MID Bottom View
Table 3-23 Main Chassis and MID Bottom View
Item No. Description Qty Part Number
1 Rib Bracket 1 E8251-00008
2 Cable Retainer Clip 3 E8251-40001
3 Screw-Machine M30. x 8 CW-PN-TX (A31 Motherboard to main chassis) 15 0515-0372
4 Screw-Machine M30. x 8 CW-PN-TX (A28 YIG Oscillator to MID) 2 0515-0372
5 Screw-Machine M30. x 20 CW-PN-TX (A30 Modulator Filter with Standard or High Power to MID) 3 0515-1410
6 Screw-Machine M30. x 20 CW-PN-TX (A29 20 GHz Doubler to MID) 2 0515-1410
