U8903A Quick Start Guide 9
Table 3 U8903A rear panel description
No. Item Description
1 Trigger in Receives an external TTL or CMOS signal using a female BNC input connector for
triggering operation. Triggering can occurs on either the positive or negative edge.
2 Fuse Fuse compartment for AC supply
3 AC power inlet Connects to an AC line voltage
4 VGA port Allows an external monitor to be connected to the U8903A
5 LAN port Allows the U8903A to be controlled remotely over the LAN interface
6 USB Type-B port Allows the U8903A to be controlled remotely over the USB interface
7 USB port Allows an external USB flash storage to be connected to the U8903A
8 GPIB port Allows the U8903A to be controlled remotely over the General Purpose Interface
Bus (GPIB) interface
9
Sync in
Receives an external sync in clock/frame signal using a female BNC input
connector (for digital audio only)
10 Digital analyzer input and
output (AES3/SPDIF)
Receives and outputs digital audio signal using a female BNC input connector and
a female BNC output connector respectively
11 Digital analyzer input and
output (DSI)
Receives and outputs digital audio signals using a 25-pin male D-SUB connector
12 Digital analyzer input and
output (SPDIF)
Receives and outputs digital audio signal using a TOSLINK input connector and a
TOSLINK output connector respectively
13 Digital analyzer input and
output (AES3)
Receives and outputs digital audio signal using a female XLR input connector and
a male XLR output connector respectively
