12 U8903A Quick Start Guide
Power On the U8903A
Connect one end of the power cord to the U8903A rear
panel AC power inlet and the other end to an AC voltage
source. The U8903A will automatically adjust to the correct
line voltage in the range of 100 Vac to 240 Vac.
Preset the U8903A
A preset does not erase the flash memory, state memory, or
I/O configuration. A preset will delete all customized settings
on the U8903A.
To preset the U8903A, you can perform either one of the
following steps.
• Send the *RST, SYSTem:PRESet,
SYSTem:RESet[:MODE], or SYSTem:RESet:CHANnel
SCPI commands from the PC via the USB, GPIB, or LAN
interface.
• Press on the System panel.
Presetting the U8903A will not reset the HP8903B configurations and the
Legacy Sweep setting.
