EMC Information
Table 204 Guidance and Manufacturer's Declaration - Immunity Equipment and Systems which are
NOT Life-supporting
Electromagnetic Environment Guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC
61000-4-3
3 VRMS
.15 MHz to 80 MHz
3 V/m
80 MHz to 2.5
GHz
(V1) VRMS = 3
(E1) V/m = 3
Portable and mobile communications
equipment should be separated from the
control unit by no less than the distances
calculated/listed below:
D = (3.5/V1) (SQRT P)
D = (3.5/E1) (SQRT P)
80 to 800 MHz
D = (7/E1) (SQRT P)
800 MHz to 2.5 GHz
Where P is the max power in watts and D is the
recommended separation distance in meters.
Field strengths from fixed transmitters, as
determined by an electromagnetic site survey,
should be less than the compliance levels (V1
and E1).
Interference may occur in the vicinity of
equipment containing a transmitter.
IFU0000073 Immerse User Manual
