1 GENERAL INFORMATION
1.1 SYSTEM DESCRIPTION
The Asp-Micro handheld observational thermal monocular is equipped with a
160×120 or 384×288 infrared detector and a 720×540 LCOS display. It supports
functions of observation, highest temperature target tracking, distance
measurement, Wi-Fi hotspot, and so on. The high-sensitivity built-in thermal
detector provides you with clear view even in total darkness. The monocular is
mainly applied to scenarios such as patrolling, law enforcement, searching and
rescuing, drug enforcement, anti-smuggling, criminal seizing, hiking, travel,
and hunting, etc.
TABLE 1-1. MAIN PARTS
ITEM DESCRIPTION ITEM DESCRIPTION
1 Body 7 Diopter Adjustment Knob
2 Lens Cap 8 Eyepiece
3 POWER Button 9 USB Interface Cover
4 CAPTURE Button 10 Tripod Screw
5 MODE Button 11 Battery Status Indicator
6 ZOOM Button 12 USB type C Interface
FIGURE 1-1. MAIN PARTS
11
10
12
1
2
3
4
5
6
7
8
9
