11PVS-14 USER MANUAL
2 OPERATING INSTRUCTIONS
2.1 CONTROLS AND INDICATORS
NOTE:
The PVS-14 is a precision electro-optical instrument and must be handled carefully at all times to
prevent injury to the user or damage to the device. If the equipment fails to operate, refer to the
Troubleshooting Procedures in Chapter 4.
The PVS-14 can be adjusted to accommodate most differences in physical size and eyesight. The
controls and indicators for the PVS-14 are shown in Figure 2-1 and described in Table 2-1.
FIGURE 2-1. MONOCULAR CONTROLS AND INDICATORS
OBJECTIVE FOCUS
DIOPTER ADJUSTMENT
POWER
SWITCH
GAIN CONTROL
EYE RELIEF
ADJUSTMENT
HIGH LIGHT CUT-OFF WINDOW
IR LENS
LATCH
BATTERY POLARITY
INDICATOR (HIDDEN)
