34 AGM Global Vision
5 SPECIFICATIONS
5.1 SPECIFICATIONS
The following tables provide information pertaining to the operational, electrical, mechanical,
optical, and environmental characteristics of the monocular.
TABLE 5-1. OPERATOR ADJUSTMENT LIMITS
ITEM LIMITS
Diopter Focus +2 to -6 diopters
Objective Focus 9.8 in / 25 cm to infinity
TABLE 5-2. ELECTRICAL DATA
ITEM DATA
Power Source Battery (1.5 Vdc max ea.)
Battery Requirements One AA Alkaline or one AA 1.5 Vdc Lithium L91
TABLE 5-3. MECHANICAL DATA
ITEM DATA
Carrying Case Size: Approx. 14 x 9.5 x 8 in / 352 x 240 x 200 mm
Monocular (see Note)
Size: 4.5 x 2.0 x 2.2 in / 114 x 51 x 57 mm
Weight: 12.4 oz / 0.35 kg
NOTE:
The size of the monocular does not include lens cap and eyecup.
The weight of the monocular does not include accessories.
