Lookforthissymboltopointoutimportantsafetyprecautions.Itmeans—Attention!! Become
alert!! Your safety is involved.
RULES FOR SAFE OPERATION
SAFETYRULES ............................................................. 2
CARTONCONTENTS .................................................... 2
FULLSIZEHARDWARECHART ................................... 3
ASSEMBLY ..................................................................... 4
OPERATION ..................................................................11
MAINTENANCE ........................................................... 12
1. Readthetractorandsnowbladeowner'smanualsand
knowhowtooperateyourtractorbeforeusingtractor
withsnowbladeattachment.
2. Neveroperatetractorandsnowbladewithoutwearing
properclothingsuitedtoweatherconditionsandoperation
ofcontrols.
3. Neverallowchildrentooperatetractorandsnowblade,
and do not allow adults to operate without proper
instructions.
4. Alwaysbeginwithtransmissioninrst(low)gearand
graduallyincreasespeedasrequired.
Anypowerequipmentcancauseinjuryifoperatedimproperlyoriftheuserdoesnotunderstandhowtooperatetheequipment.
Exercisecautionatalltimes,whenusingpowerequipment.
CARTON CONTENTS
REF. QTY. DESCRIPTION
REF. QTY. DESCRIPTION
1 1 LongHangerBracket
 2 1 ShortHangerBracket
 3 1 RearMountingBracket
 4 1 PivotSupportBracket
 5 1 ThrustChannel 
 6 1 ChannelAssembly
 7 1 BladeAssembly
 8 1 BladePivotRod
 9 1 LiftHandleTube
10 1 LiftHandleRod
 11 2 RearSupportChannel
 12 1 Cable
 13 1 RearLocatingBracket
 14 1 GripAssembly
 15 1 BladeAdjustSpring
 16 2 AngleLockBars
 17 2 FrameBracket
 18 1 BladePivotShaft
8
12
9
2
1
3
4
6
11
7
5
10
15
18
16
14
17
13
