Agri-Fab LBD48D - Long Hanger Bracket; Short Hanger Bracket

5
JOHN DEERE LT TRACTOR
W
L
H
FIGURE 2
STEP 2: (SEE FIGURE 2)
• MeasurethedistancesL,HandW.
 L= distancefromcenteroflowerholesinframe 
 brackettofrontoftractorframe.
 H=distancetocenterofholeinframebracketthatis
closesttobeing6"abovegroundlevel.
 W=distancebetweentheinsideoftheframebrackets.
• Proceedtostep4.
FIGURE 3 - SEARS TRACTOR SHOWN
W
SEARS (LT) TRACTOR FRAME
H
DECK SUSPENSION
BRACKET
G
R
O
UND
L
STEP 3: (SEE FIGURE 3)
• MeasurethedistancesL,HandW.
 L= distancefromcenterofholeindecksuspension
 brackettofrontoftractorframe.
 H=distancefromcenterofholeindecksuspension 
 brackettogroundlevel.
 W=insidedistancebetweenthedecksuspension 
 brackets.
USE THESE INSTRUCTIONS IF YOUR
TRACTOR HAS TWO FRONT BRACKETS
FOR ATTACHING THE MOWER DECK
ATTENTION:Gobacktostep1ifyourtractorhasonlyone
frontbracketforattachingthemowerdeck.
3/8" x 1-1/4"
CARRIAGE BOLT (E)
3/8" NYLOCK NUT (I)
LONG HANGER BRACKETS
Ends down when "H" is 6" or less
Ends up when "H" is more than 6"
W
L+
FRONT PLATE
FIGURE 4
STEP 4: (SEE FIGURE 4)
Refertopage6forexamplesofhowtoattachtheHanger
Bracketstosomeothertractormodels.
• SelectthepairofslotsinthetopoftheThrustChannel
thatwillprovideenoughclearancebetweentheblade
andthefrontofthetractorwhileminimizingoverhang.
 Selectthepairofslotsbasedondistance"L"measured
instep2orstep3.
 L=5"orless Attachtothefrontpairofslots.
 L=5"to7" Attachtothemiddlepairofslots.
 L=7"to9" Attachtotherearpairofslots.
• Arrange the Hanger Brackets with the short Hanger
BracketontheinsideofthelongHangerBracketand
placethemontopoftheThrustChannel. Ifdistance
"H",measuredinstep2or3,islessthan6",pointthe
bracketsdown.Ifdistance"H"ismorethan6",pointthe
bracketsup.
• AdjustthewidthoftheHangerBracketstojustslightly
lessthandistance"W"measuredinstep2or3.Center
thebracketsontheThrustChannelandattachthem
usingtwo3/8"x1-1/4"carriageboltsand3/8"nylock
nuts.
• Tighten the nuts and then make sure the hanger
bracketstbetweenthedecksuspensionbracketsor
framebracektsonthetractor.
• Proceedtostep5onpage7.
USE THESE INSTRUCTIONS FOR ALL
TRACTORS
