STEP 9: (SEE FIGURE 9)
• Assemblethepivotsupportbrackettothefrontofthe
ThrustChannelusingfour3/8"x1"carriageboltsand
four3/8"nylocknuts.Makesurethebracketisstraight
andthentighten.
FIGURE 7
FIGURE 9
FIGURE 8
FIGURE 5
FIGURE 6
ENGLISH
STEP 5: (SEE FIGURE 5)
• AttachtheRearLocatingBrackettothetopoftheRear
MountingBracketusingtwo3/8"x1"Carriageboltsand
3/8"nylocknuts.Tightennuts.
• AttachtheRearSupportChannelstothemiddlesetof
holesinthesidesoftheRearMountingBracketusing
four3/8"x1"CarriageBoltsand3/8"nylocknuts.Finger
tighten only.
REAR SUPPORT
CHANNELS
REAR MOUNTING
BRACKET
REAR LOCATING
BRACKET
3/8" x 1"
CARRIAGE BOLT (F)
3/8" NYLOCK NUT (I)
STEP 6: (SEE FIGURE 6)
• SlidetheRearSupportChannelsundertherearofthe
tractor.AttachtheRearMountingBrackettotheTractor
Drawbarusingthe5/8"x1-3/4"ClevisPinandalarge
HairpinCotter.
5/8" x 1-3/4"
CLEVIS PIN (K)
LARGE
HAIRPIN
COTTER (M)
REAR
MOUNTING
BRACKET
REAR LOCATING
BRACKET
REAR SUPPORT
CHANNEL
STEP 7: (SEE FIGURE 7)
• SlidetheThrustChannelunderthefrontofthetractor.
AttachtheHangerBracketstotheFrameBracketsor
DeckSuspensionBracketsusingtwo1/2"x1"clevis
pins,1/2"washersandlargehairpincotters.
STEP 8: (SEE FIGURE 8)
• PlacetheThrustChannelbetweenthetwoRearSupport
Channels.Installfour3/8"x1"carriageboltsand3/8"
nylocknutsusingthe mostwidelyspaced holes that
alignwithslots.Finger tighten only.
• IftheRearSupportChannelsbumpagainstthebottom
ofthetractor,reattachtherearofthechannelstoalower
setofholesintheRearMountingBracket.Ifthereismore
clearancethannecessarybetweentheRearSupport
Channels and the bottom of the tractor, reattach the
rearofthechannelstoahighersetofholesintheRear
MountingBracket.
• Tightenallboltsandnutsinstalleduptothispoint.
• Measure the height of the front plate on theThrust
Channel.Ifitisnot4"to5"abovetheground,reinstall
theclevispinsintheHangerBracketstoahigheror
lowerholepositiontoattainthecorrectheight.
THRUST
CHANNEL
1" x 1/2" CLEVIS
PIN (L)
LARGE HAIRPIN
COTTER (M)
1/2" WASHER (S)
REAR
SUPPORT
CHANNELS
FRONT
PLATE
3/8" x 1"
CARRIAGE BOLT (F)
3/8" NYLOCK
NUT (I)
4" to 5"
GROUND
3/8" x 1"
CARRIAGE BOLT (F)
3/8" NYLOCK
NUT (I)
