EN
Operator's Manual
BM
Kullanım Kılavuzu
10. TROUBLESHOOTING
Problem 1 : Cutting of general security bolt
Possible Cause 1 : There may be a hard matter in seed or fertilizer
box
Suggestion 1 : Check both boxes, use a new fuse pin
Problem 2 : Fertilizer's safety pin is cut
Possible Cause 2 : Blockings in fertilizer dropper and mixer
Suggestion 2 : Check fertilizer box and mixer, use a new pin
Problem 3 : Planting pinion is broken
Possible Cause 3 : There may be a hard matter in seed
Suggestion 3 : Use a new pinion
Problem 4 : Fertilizer dropping pinions are broken
Possible Cause 4 : There may be a hard matter in fertilizer Box
Suggestion 4 : Use a new pinion
Problem 5 : Planting discs don't turn
Possible Cause 5 : New paint may be holding the disk, a stone
may have gone through the boot, etc.
Suggestion 5a : Discs should be exercised.
Suggestion 5b : Thing that has gone through should be got
out.
Problem 6 : Fertilizer dropping pulley gutters are lled.
Possible Cause 6 : Humid and dry fertilizer are used together
Suggestion 6 : Fertilizer gutter should be cleaned
Problem 7 : Automatic's chain is released
Possible Cause 7 : Chain is loosen, gears are working omitting
Suggestion 7 : Chain should be tightened and gears should
be in a row.
Problem 8 : Wheel's chain is released
Possible Cause 8 : Chain is too tight, gears are omitting.
Suggestion 8 : Stretching arch should be checked
Problem 9 : Seed planting axle is twisted
Possible Cause 9 : Hard matter in seed box
Suggestion 9 : Replace the axle
Problem 10 : Grasping gear doesn't grasp
Possible Cause 10 : Planting feet are twisted
Suggestion 10 : Check the grasp cock and grasp arch.
Suggestion 10 : A new arch, axle should be used
Problem 11 : Space in seed degree lever
Possible Cause 11 : Abrasion of degree bed rubbing the turning
pulleys in time.
Suggestion 11 : Put plake into both sides of the bed
Problem 12 : Some of the seed boxes drop zirregularly
Possible Cause 12 : Sliding or loosening of box screws
Suggestion 12 : Bring the degree down 'O', screw the ones
where pulley is not seen in bed.
Suggestion 12 : Make the calibration setting
10. SORUN ÇÖZME
Sorun 1 : Genel güvenlk cıvatası keslmş se
Olası Neden 1 : Tohum sandığı çnde sert madde olablr
Çözüm 1 : Tohum sandığını kontrol ednz, keslmş cıvatayı
değştrnz
Sorun 2 : Gübre güvenlk pm keslmş se
Olası Neden 2 : Gübre atıcı veya karıştırıcıda tıkanma olablr
Çözüm 2 : Gübre sandığını ve karıştırıcıyı kontrol ednz, pm
değştrnz
Sorun 3 : Ekc pnyon kırılmış se
Olası Neden 3 : Tohumun çnde sert madde olablr
Çözüm 3 : Pnyonu değştrnz
Sorun 4 : Gübre atıcı pnyonlar kırılmış se
Olası Neden 4 : Gübre sandığında sert madde olablr
Çözüm 4 : Pnyonu değştrnz
Sorun 5 : Ekc dskler dönmüyor se
Olası Neden 5 : Dskler yen boyandığında olablr. Ayaklar arasına
taş sıkışmış olablr
Çözüm 5a : Dskler döndürülmeldr
Çözüm 5b : Sıkışmış taş çıkarılmalıdır
Sorun 6 : Gübre atıcı kasnak yarığı dolmuş se
Olası Neden 6 : Çamur veya nem gübre doldurmuş olablr
Çözüm 6 : Kasnağı temzleynz
Sorun 7 : Otomatk sstem zncr çıkmış se
Olası Neden 7 : Zncr gevşemş olablrDşler çıkmış olablr
Çözüm 7 : Zncr gernz, dşller ayarlayınız
Sorun 8 : Teker zncr çıkmış se
Olası Neden 8 : Zncr çok gerlmş olablr, dşller çıkmış olablr
Çözüm 8 : Germe kavsn kontrol ednz
Sorun 9 : Ekc dsk ml burulmuş se
Olası Neden 9 : Tohum sandığında sert madde olablr
Çözüm 9 : Ml değştrnz
Sorun 10 : Kavrama dşls kavramıyor se
Olası Neden 10 : Ekc ayaklar burulmuş olablr.
Çözüm 10a : Kavs ve ml değştrnz
Çözüm 10b : Kavrama takozunu ve kavsn kontrol ednz
Sorun 11 : Tohum derece kolunda boşluk var se
Olası Neden 11 : Kol bağlantı noktası sürtünmeden dolayı aşınmış
Çözüm 11 : Her k bağlantı noktasına levha koyunuz
Sorun 12 : Tohum dağıtıcılardan bazıları düzensz çalışıyor se
Olası Neden 12 : Dağıtıcı kutuların vdaları kaymış veya gevşemş
olablr
Çözüm 12 : Derecey aşağı ndrnz, ölçümleme ayarlamalarını
yapınız
23
WARNING
The maintenance that explained in this manual
are valid for normal terms of use. So they can be
changed according to working and weather
conditions.
Clean the grease nipple before lubricating to
prevent decreasing the oil quality according to
mixing of dust and foreign materials with oil. This cleanness is
increased the efficiency of lubricating.
UYARI
Bu ktapta açıklanan bakım peryotları sadece
yol gösterc ntelktedr ve normal kullanım
koşulları çn geçerldr. Dolayısıyla, çalışma
koşullarına (tozlu, vb.), klm durumlarına göre bu
peryotlar değşklğe uğrayablr.
Toz ve yabancı maddelern gresle karışıp,
yağlanma kaltesn düşürmesn önlemek çn, gres basmadan
önce gresörlükler temzleynz. Bu temzlk, yapacağınız
yağlamanın etknlğn artıracaktır.
TR
22
11. HOW TO USE “SPARE PARTS CATALOGUE”?
“Spare Parts Catalogue” containing illustrated parts lists to
enable maintenance and parts personnel to identify items
and assemblies, is a tool to contact us or our services and to
get parts you need on time.
This catalogue consists of mainly two different pages
format named “Illustration Page Format” and “Part
Identication Page Format”. Each part is identied separately
by numbers on the illustrations located in “Illustration Page
Format” called “REF NO.” These “REF NO” are also located in
“Part Identication Page Format”. On the same line “PART NO”,
“DESCRIPTION”, “QUANTITY” and “TECHNICAL
SPECIFICATIONS” are located.
,11.1. TO FIND NECESSARY PART STEP BY STEP
1- Find Illustration Page of necessary part group by using
“INDEX”,
2- Find “REF NO” of the spare part from Illustration Page,
3- Find the line the “REF NO” from the table,
4- Find “PART NO” at that line and indentify this number in
your orders.
