3 Product description
3.1 General information
AHT products comply with EU Regulation 1907/2006
(REACH) on the Registration, Evaluation, Authorisa-
tion and Restriction of Chemicals.
Neither refrigerant R-290 nor the blowing agent
pentane have an ozone depletion potential (ODP).
R-290 has a very low global warming potential (GWP)
of 3.
3.2 Technical data
Important technical data can be found on the serial
plate (see →Rating plate and serial number).
Parameter Value
External dimen-
sions
See →Appliance model
overview
Weight of unit
See →Appliance model
overview
Refrigerant Propane (R-290)
Airborne noise
emissions/ Emission
sound pressure
level
< 70 dB(A)
M-package temper-
ature class (product
temperature class)
according to EN
ISO 23953-2
M2
Maximum load
Parameter Value
AC-S, AC-M, AC-W, (AC-XL)
Shelf
30 kg (85 kg)
Base shelf
30 kg (85 kg)
AC-S, AC-W
Number of shelves 3 Piece
AC-M, AC-XL
Number of shelves 4 Piece
Electrical connection
Parameter Value
Rated voltage/rated
frequency
220 – 240 V/50 Hz
Plug types CEE 7/7
Plug types
Country-specific
Minimum cross-sec-
tion for connection
cable
1.5 mm²
Connection cable 3-pin cable
Fusing
See →Fusing
Rated
cur-
rent
[A]
Trig-
gering
current
[mA]
Type Trip
charac-
teristic
Circuit breaker (LS/CB)
16 - -
C (time-
lag)
Residual current circuit breaker (FI/RCCB/GFCI)
40 30
G (short time delay)
A (pulse current
sensitive)/
F (sensitive to mixing
frequency)/
B (sensitive to universal
current)
-
Combination switch FI-LS/RCBO (alternative to FI
and LS)
16 30
G (short time delay)
A (pulse current
sensitive)/
F (sensitive to mixing
frequency)/
B (sensitive to universal
current)
C (time-
lag)
Custom deviations possible.
Further information: Maintenance services (see
→Maintenance services).
3.2.1 Rating plate and serial number
Observe the information on the rating plate.
The rating plate is a sticker on the back of the appli-
ance.
Information on rating plate
– Model and unit type
– Serial number
– Climate class*
– Nominal voltage and nominal frequency
– Nominal current and nominal consumption
– Refrigerant and quantity used
– Net volume
– Date of manufacture
– and other technical data
*Examples of climate classes:
Climate class
according to
ISO 23953-2
Ambient tem-
perature [°C]
Relative humid-
ity [%]
3 25 60
3.3 Proper use
The appliance is intended for the display of packaged,
refrigerated food products or access to them by cus-
tomers.
For more information, see →Proper use
4 Structure and function
The appliance is a compact device ready to plug in.
The appliance is pre-programmed ex works.
The appliance contains one or more hermetically
sealed refrigerant circuits whose components are per-
manently and technically tightly connected to each
other.
