AIDA HD-100A - WB CONTROL; AE CONTROL; AUTO Mode

6
AWB - Auto white balance mode will adjust white balance within
3,000˜K ~ 8,000˜K temperature.
ATW - Auto trace white mode will adjust white balance within
1,900˜K ~ 11,000˜K temperature.
ONE PUSH - One push mode is used if AWB or ATW cannot produce the proper
white balance. Place a white paper in front of the camera when using the one push
mode to self adapt.
INDOOR - Indoor mode will adjust white balance to indoor lighting conditions.
OUTDOOR - Outdoor mode will adjust white balance to outdoor lighting conditions.
MANUAL - Manual mode will adjust white balance manually.
BLUE - 0 ~ 100 ( Select blue gain within the range of 0 to 100 )
RED - 0 ~ 100 ( Select Red gain within the range of 0 to 100 )
WB CONTROL
AE CONTROL
AUTO
• AGC MAX : OFF, LOW, MIDDLE, HIGH, DMIN, DMID, DMAX
“AGC MAX” sets the maximum gain value to control the video noise caused by
Auto Gain Control.
• SENS UP : OFF, x2 ~ x10
“SENS UP” mode controls the digital slow shutter to allow extra light into the
camera and adjust the picture quality.
• AE BRIGHT : 0~20 - ( Auto Exposure brightness level can be adjusted )
Auto mode will adjust the exposure level automatically.
Detailed ne tuning options are available under this menu.
WHITE BALANCE
*MODE AT W
PUSH
BLUE
RED
RETURN
AE CONTROL
*AE MODE AUTO
SHUTTER
IRIS
AGC
AGC MAX 13
SENS UP OFF
AE BRIGHT 6
FLK CONTROL OFF
LENS MODE MANUAL
RETURN
