11
Interfaces
Full digital remote control facilities are available through LAN, USB and optional GPIB interfaces.
LAN Interface
Ethernet 100/10base – T hardware connection. LXI Core 2011.
USB Interface
Standard USB 2.0 hardware connection. Implemented as virtual-COM port.
USB Flash Drive
For waveform and set-up storage/recall.
GPIB (optional)
Conforming with IEEE488.1 and IEEE488.2
General
Display: 256 x 112 pixel monochrome graphics display. White LED backlight with
adjustable brightness and contrast. Black-on-white or inverse modes.
Data Entry: Keyboard selection of mode, waveform etc.; value entry direct by numeric
keys or by rotary control.
Stored Settings:
Up to 9 complete instrument set−ups may be stored and recalled from
non-volatile memory.
Size: Bench Top:
TG2511A/TG5011A - 97mm(H) x 250mm(W) x 270mm(L)
TG2512A/TG5012A - 97mm(H) x 250mm(W) x 295mm(L)
Rack mount:
TG2511A/TG5011A - 86.5mm (2U) x 213.5mm (½−rack) width x 244mm(L)
TG2512A/TG5012A - 86.5mm (2U) x 213.5mm (½−rack) width x 269mm(L)
Weight: TG2511A/TG5011A – 2.55kg
TG2512A/TG5012A - 2.7kg
Power: 110-240VAC ±10% 50/60Hz; 100-120VAC ±10% 400Hz; 60VA max.
Installation Category II.
Operating Range:
+5°C to 40°C, 20−80% RH.
Storage Range:
−20°C to + 60°C.
Environmental:
Indoor use at altitudes up to 2000m, Pollution Degree 2.
Options:
19 inch rack mounting kit.
Safety & EMC: Complies with EN61010-1 & EN61326-1.
For details, request the EU Declaration of Conformity for this instrument
via http://www.aimtti.com/support (serial no. needed).
