AIMS Power PWRI150024S - User Manual

10 pages

Save Page as PDF

To Next Page

DC TO AC PURE SINE POWER INVERTER

PWRI150024S / PWRI150048S

INSTRUCTION MANUAL

Main Page

Questions and Answers

C
campbelljeromeJul 28, 2025
What to do if my AIMS Power Inverter has no output voltage and the buzzer sounds continuously?
- L
  longtinaJul 28, 2025
  If your AIMS Power Inverter isn't providing output voltage and the buzzer is continuously sounding, it could be due to several reasons: * **Low input DC voltage:** Recharge or replace the battery. * **High input DC voltage:** (Solution not mentioned in the provided information.) * **Overload:** Try reducing the load power. * **Over temperature:** Cut off the load and allow the inverter to cool for 10 to 30 minutes. After it returns to a normal temperature, restart it. Ensure that the load power is within the rated power range, that the vents are not blocked, that ventilation is improved and the ambient temperature is reduced. Also, avoid using the inverter while the battery is charging and confirm that the battery's rated voltage is within the inverter's input voltage range.
M
Mrs. Marie Mcguire MDAug 10, 2025
Why is my AIMS Power PWRI150024S not driving the load?
- K
  Kerry ThomasAug 10, 2025
  Your AIMS Power Inverter might fail to drive the load because the load power is too large, or the appliance's actual power exceeds the inverter's nominal power. Try reducing the load power or turning on the appliance before turning on the inverter. Also, if the starting power is larger than the rated power, the internal inverter soft-start circuit will buffer starting the appliance.

Summary

Introduction

Warning and Safety

General Safety Precautions

Covers manual reading, environmental conditions, disassembly, servicing, grounding, alcohol/drugs, pacemakers, ventilation, unintentional start, children, and handling of AC outlets.

Inverter Features

Key Features Overview

Highlights dual outlets, USB port, LED indicators, easy switch, remote port, cooling fan, low battery protection, high voltage protection, overload, and short circuit protection.

Installation

Installation Requirements

Specifies space, temperature, ventilation, and mounting orientation for inverter installation.

Battery

Battery Requirements and Sizing

Covers DC input voltage, current capacity, load calculation, efficiency loss, and battery run time estimation.

Connection

Grounding the Inverter

Explains how to connect the inverter's ground terminal to the vehicle, boat, or earth ground.

Connecting Battery Terminals

Details the correct procedure for connecting positive and negative battery cables, warning against polarity reversal.

Using the Power Inverter

Operation Steps

Covers checking battery, connecting inverter, powering on, plugging appliances, and shutdown procedures, including fan operation and long-term storage.

Soft Start Technology

Output Voltage & Waveform

Inverter Protections

Inverter Protection Features

Covers input under-voltage, under-voltage, over-voltage, overload, short-circuit, and thermal protection with alarm indicators.

Hi-Pot Testing

Troubleshooting

Troubleshooting Common Issues

Addresses no output voltage, incorrect output voltage, and load driving issues with their causes and solutions.

Specifications

Model Specifications

Details DC input voltage, output waveform, power, efficiency, operating temperature, protections, and dimensions for both models.

Warranty

Warranty Information and Voiding Conditions

Covers contact information, warranty period, exclusions, and specific actions that will void the warranty.

AIMS Power PWRI150024S Specifications

General

Model	PWRI150024S
Power Output	1500W
Continuous Output Power	1500W
Input Voltage	24V DC
Output Voltage	120V AC
Output Waveform	Pure Sine Wave
Peak Power	3000W
Surge Rating	3000W
Efficiency	90%
Cooling	Fan Cooled
Protection Features	Overload, Over Temperature, Short Circuit
