Aiphone GT-1A - Indicators

- 8 -
ENTRANCE STATION
2
B
A
C
3
E
D
F
5
K
J
L
8
U
T
V
4
H
G
I
6
N
M
O
1
0
9
Y
X
W
Z
7
R
Q
P
S
Indication patterns
1 IN USE LED
(orange)
2 Call
indicator
3 Talk
indicator
4 Door
release
indicator
5 Display
Standby Off Off Off Off
W E L C O M E
(*3)
System in use
Lit
Off Off Off
I N U S E
Call Off
Lit
Off Off
(
*
1)
C A L L I N G
S M I T H
(*3)
Communication Off Off
Lit
Off
(
*
2)
I N C O M M U N I C A T I O N
Releasing a door Off Off
(
*
1)
Off
(
*
2)
Lit
D O O R O P E N
Monitoring Off Off Off Off
W E L C O M E
Communication is on hold
Lit
Off Off Off
O N H O L D
(
*
1): Lit when door release is activated during call.
(
*
2): Lit when door release is activated during communication.
(
*
3): The display differs depending on the settings.
5
1
4
1
2
2
34
3
Indicator
Status
Entrance station (modular type) Entrance station (all-in-one type)
Indicators
1-3
