GETTING STARTED
USING THE SYSTEM
APPENDIX
SETTING AND ADJUSTMENT
Power supply unit (IS-PU-UL, IS-PU-S)
Power source
AC 100 - 240V
, 50/60Hz.
Power consumption
120W
Ambient temperature
0 - 40°C (+32°F - +104°F)
(Secondary) Output
voltage
DC 48V
(Secondary) Output
current
2.1A
Mounting
W
all-mount (with IS-RACK) or rack-mount
(with IS-RACK)
Material
Steel plate
Color
Black
Weight
Approx.1.5kg (3.31 lbs.)
