Aiphone IX SERIES Setting Manual

23
Other
Appendix
5
Specifications
Maintenance
• Clean the station gently with a soft, dry cloth. For difficult stains, dip a soft cloth in neutral detergent diluted with
water, wring it out well, and then clean unit.
Power PoE (IEEE802.3af Class 0 standard)
Current Consumption Standby: 43 mA; Maximum: 135 mA
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Protocol IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
Encryption system TLS1.0, TLS1.1, TLS1.2
Operating temperature -10 - +50℃
Mounting Wall-mounting
Materials Fire-retardant resin
Color White
Dimensions 245 mm (9-5/8") (W) x 190 mm (7-1/2") (H) x 21 mm (13/16") (D)
(excluding the embedding area)
Weight 630 g (approx.) (1.39 lbs)
Important
• Do not use chemicals such as benzene or paint thinner. You may damage the surface of the station, or cause discoloration.

Aiphone IX SERIES Specifications

General

Series	IX Series
Communication	IP Network
Audio	Yes
Video Codec	H.264
Network	Ethernet
Video	Yes
Integration	Yes
Security	Encrypted Communication
Power	PoE (IEEE 802.3af)
Video Resolution	720p HD
Audio Codec	G.711
Mounting	Wall Mount
Relay Outputs	Yes
Inputs	Yes
Relative Humidity	90% or less, non-condensing
Audio Output	Speaker (Internal or External)
Audio Input	Built-in Microphone
Type	Video Intercom
