6 | IXG Quick Start Programming Guide
Site Settings (continued)
The IXG Series can use dierent unit types to support a variety of applications. Here are some common use
cases and solutions to achieve those goals.
Sample Unit Layouts
Single Oce (1 Door Station, 1 Master Station, 8 Mobile Apps)
For this size of oce, everything can be placed in a single commercial unit.
Single Oce (3 Door Stations, 1 Master Station, 8 Mobile Apps)
To accomodate more than two doors calling to a single oce, place the master station and mobile apps in a
commercial unit, and the three door stations in an outside area.
Multi-Tenant, App Only (2 Entrance Stations, 4 Tenants, 8 Mobile Apps per Tenant)
For apartment buildings where the tenants only have mobile apps, place IXG-DM7-HID* entrance stations in an
entrance unit, and make a seperate residential unit with mobile apps for each apartment.
Multi-Tenant (1 Entrance Station, 4 Tenants, 1 Tenant Station and 4 Mobile Apps per Tenant)
For apartment buildings, place IXG-DM7-HID* entrance station in an entrance unit, and place the master station
and mobile apps for each apartment in separate residential units.
To nish conguring
the stations in the
Outside Area and
Commercial Unit
for calling, see
Station Partitioning
on page 14.
