5
Association Settings
Advanced View
The following settings are found under the Advanced View in Support Tool. Click View on the top menu and select
Advanced to switch views.
System Information
From the side menu, expand System Information and select Station List. Here, use the drop-down boxes under Select to
place a check mark between every master station the stations that should be on its Station List.
Doing this allows master stations to call to these stations, as well as enables features like monitoring and door release
when the Update button is pressed. Removing check marks is also a way to partition a system and prevent stations from
communicating to one another.
Station List
Enable calling and communication between stations and Mobile Apps the same way by expanding System Information
and selecting Mobile App List.
Mobile App List
This is a setting specically for master
stations. Continue with the next steps
to enable the same functions for Mobile
Apps and Door Stations.
From the top menu, select Connection and click Association Settings. Here, stations created in the previous steps will be
associated to stations found on the network. Select a station from the Station Settings List and one from the Station List
below. Clicking Apply will assign the Station Name and IP Address to the station, and that station will quickly reboot.
Typically, stations deployed across a
managed network cannot be found
by Support Tool unless the network
is congured to allow this broadcast
search. In this case, it may be easier
to move the stations to a switch local
to the programming PC than it would
be to congure the network to allow
a network-wide broadcast.
If a Station Search fails immediately, go to File from the top menu and select IXG Support Tool Settings. Find the
Select NIC drop-down and select the correct NIC Support Tool should use, and click Okay . Return to Association Settings
to try again. If the Station Search continues to fail immediately, a local antivirus or rewall may be preventing this
action. Disabling either of these during the short programming process may be a simple solution in nishing the system
conguration.
Station Settings and Station List
