Page #6 background imageLoading...
Page #6 background image
– 6 –
Model Cable Wire number
LEF-3 9 conductors #822210 (22AWG, 10 cond.)
LEF-5 12 conductors #822212 (22AWG, 12 cond.)
LEF-10 17 conductors #822220 (22AWG, 20 cond.)
LEF-10S 20 conductors #822220 (22AWG, 20 cond.)
LE Subs 3 conductors #822203 or #821803 (22AWG, 3 cond.)
Wiring Diagrams
Three LEF-3 and One Door Station
Two LEF-3 and 2 Door Stations
LEF All-Master configuration
LEF all-master systems are designed to be wired in a looped fashion from the first to last master. The number of conductors for a
system (not including “K” for terminals) are:
• A single-master system can be wired with 2 conductors homerun from each sub. (Wire #822202 or #821802 in USA)
Cable requirements
Use multi-conductor cable with an overall shield, non-twisted, 22AWG to 18AWG (0.65mm to 1.0mm), to accommodate the
maximum number stations in the system, each of which requires one designated wire, plus up to nine common wires per system,
depending on features used. Selective door release adds one additional wire per door being released. Use the gauge specified
for the maximum distance between the two farthest stations.
Power supply
The entire LEF system can be powered by one power supply (PS-1225UL, PS-1225S, 12VDC, 2.5A), located near the center of
the wire run.
For a system including the All Call and Chime with the BG-10C, one PS-1225UL(S) will power the BG-10C and the LEF system.
E
: PS-1225UL
PS-1225S
PS-1215DIN
PS12
: PS-1225UL
PS-1225S
PS-1215DIN
PS12
3
C
R
Y
+
+
2
E
R
Y
+
LEF-3 #1 LEF-3 #2
1
E
1
3
1
C
2
E
R
Y
+
LEF-3 #3
C
1
2
3
E
2
1
R
Y
+
C
E
LEF-3
3
E
1
R
Y
+
LEF-3
2
C
1
3
E
+
1
PS12
Remove the shorting link between
“E” and “
-
” terminals at all the LEF
masters and door/sub stations.
Remove the shorting link between
“E” and “
-
” terminals at all the LEF
masters and door/sub stations.
PS12
Note: This diagram assigns the master
stations as station 1, 2, and 3. The door
station is answered on each station's own
number terminal (1, 2, or 3 respectively).
Note: This diagram assigns both master
stations to use channel 1 to talk to the
other master. The door stations are on
channels 2 and 3 respectively.
LE-D or LE-DA
LE-D or LE-DA
LE-D or LE-DA
