Aircommand Heron Q - Page 5

Power & control cables can
follow the 6.4ø pipe
9.5ø tube insulated
LEFT HAND ENTRY
Figure Y
REAR ENTRY
Figure Z
5
9.5ø tube insulated
6.4ø tube
Ensure tubes do not touch compressor
6.4ø tube
pass out the power
& control cables
thru this entry
