MAIN COMPONENTS
1) Sparrow Mk4 Rooftop Air
conditioner
2) Weather collar assembly
3) Circular duct
4) Combined duct & brace
5) Plenum Filters x2
6) Plenum cover
FITTINGS & FIXTURES
7) M8x120mm bolts x 4
8) Hold down bars x 4
9) Plenum cover screws x 4
10) Self tapping screws x 6
BEFORE INSTALLATION
Ensure that the installation instructions have been properly read and understood.
Installation must confirm to nation wiring regulations and in particular AS3001 – 2008.
DO NOT attempt to modify or add components to the installation procedure.
This equipment must only be serviced by a licensed refrigeration mechanic.
If your installation varies from the method outlined please contact Aircommand for specialty advice.
WARNING
Failure to properly install the unit or attempting to modify it in any way can be extremely hazardous and may result in property
damage and/or personal injury.
Aircommand will not be held responsible for issues arising from incorrect or improper installation methods.
