AirCycler Bulb Eater 3 - Filter Replacement Directions; Replacing the 2 nd Stage Cartridge Filter

800.909.9709
www.AirCycle.com [16]
Filter Replacement Directions
1
st
stage Cyclone Filter will never need to be changed.
2
nd
stage Cartridge Filter required to be changed when the fault code 13 is displayed on the LCD screen.
3
rd
stage HEPA Filter required to be changed when the fault code 11 is displayed on the LCD screen.
4
th
stage Carbon Filter: The carbon filter will require changing when filter life times out (1,500 hrs). Fault code
01 will be displayed on the LCD screen.
5
th
stage final HEPA Filter required to be changed when the fault code 09 is displayed on the screen.
Spent Filters must NEVER be left exposed. Spent filters must either remain in the vacuum housing attached to
the unit, be sealed in a full drum of crushed lamps, or bagged in a zip-top bag to avoid mercury release. DO
NOT DISPOSE OF FILTERS IN THE TRASH
• Communicate/understand potential hazards by having operators review pages 24-29 of this manual
and complete online training program at www.BulbEater3Training.com
• Confirm that the Bulb Eater
®
3 is clearly “off” and not operating.
• The operator must wear safety glasses and gloves when changing any of the three Bulb Eater
®
3 filters
Replacing the 2
nd
Stage Cartridge Filter:
1. Remove the lid from the upper housing of the vacuum body. Figure 1
2. Remove the used 2
nd
stage cartridge filter from the upper housing. Figure 2, Figure 3
3. Replace the new 2
nd
stage cartridge filter in the upper housing. Figure 3
4. Replace the lid on the upper housing of the vacuum body and secure with the 4 clips. Figure 4
Figure 2:
Figure 3:
2
3
Figure 1:
1
Figure 4:
4
