The
The Bulb Eater
®
3 is capable of crushing any size linear/straight fluorescent lamp, u-tube fluorescent lamp, and compact fluorescent lamps.
Cyclone Assembly Crusher Motor Chute Safety Cover Control Panel Vacuum & Filter
(1
st
stage filter system) (for U-tube/CFL chute) (see page 4 for details) (contains 2
nd
& 3
rd
stage filters)
Entry Tube Brass Plug Assembly Airlock Assembly Lid Assembly Carbon Canister Filter
(Not to scale) (At linear lamp entry) (contains 4
th
& 5
th
stage filters)
Not pictured
48” Entry Tube Spinner Assembly 2
nd
Stage Filter 3
rd
& 5
th
Stage Filter CFL/U-Tube Chute
(located on underside of lid) (attaches on U-Tube Flange)
