1. Control Panel
2. Air Outlet
3. Display window
4. Front shell
5. Caster
6. Handle
7. Universal socket
8. Winding pillar
9. Chassis
10. Back shell
11. Filter
12. Filter
13. Drain port
14. Remote Control
15. Connector
16. Exhaust Hose
17. Adapter
18. Window kits
19. Window kits screw
(buerfly nut)
INSATALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before starng installaon.
TOOLS NEEDED
•Flat-blade Screwdriver
•Phillips Screwdriver
LOCATION REQUIREMENTS
Place the air condioner on a flat, level surface in a locaon that is at least 50cm from any wall.
NOTE: A minimum clearance of 50cm from the air condioner to the wall must be maintained to ensure proper airflow.
Maintain a minimum 50cm clearance around t
he air condioner to not block airflow.
Keep the air condioner free of any obstrucons such as drapes, curtains, blinds, etc.
The exhaust hose should be free of any obstrucons.
Do not place the air condioner on an unstable or raised surface because it could fall and cause damage or injury.
Do not place the air condioner in direct sunlight or near a heat source such as baseboard heaters, stoves, etc.
The window panel can be installed in a window with a
minimum 50 cm to a maximum 102 cm opening.
