Airflow Duplexvent BV400 - 8 Dimensions

8. Dimensions
Front View
Front View
Service Space
Top View
Top View
710
725
731
10
160
287 116
23
130 103475
Rear
Rear
Front
Front
630
610
A clear space of 600mm
should be provided in
front of the unit to allow
for servicing.
Page 9 of 32
Clearance for condensate drain
Front View
Front View
Service Space
Top View
Top View
710
725
731
10
160
287 116
23
130 103475
Rear
Rear
Front
Front
630
610
*All dimensions are in mm.
min. 110 mm.
