Airflow Duplexvent BV400 - 9.2 Pro Panel Screen

In VOD mode fan speed is controlled proportionally according to the readings from the sensor 1
(humidity sensor).
Page 12 of 32
9.2.1 Screen Symbols (Main Screen)
1. Screen 2. Screen 3. Screen 4. Screen
Screen Brightness
and Contrast Setting
Company
Introduction
Timer
Main Screen
Standard mode
Single fan mode (only
exhaust fan is running.)
Single fan mode (only
supply fan is running.)
VOD (Auto) mode
Fan speed: High
Fan speed: Med
Fan speed: Low
Fan speed: Boost
Fan speed: Auto (If unit is on VOD mode.)
Fan is off
Supply fan
Fan is on
Exhaust fan
airflow.com
9.2 Pro Panel Screen
