Thermal Fogger AT9 / AT35 Spare Part List
When ordering spare parts, please always mention the pos., part number, descriptions, number of parts
needed.
note: the part without “ # ” is commonly suitable for all appliance types.
the part with “ # ” can only be used on particular mentioned appliance type.
Pos.
Part no.
Descriptions
1
935-001-000
Solution tank
2
935-002-000
Tank cap assembly (3,4)
3
935-003-000
Cover
3/1
935-003-010
Lever indicator
4
935-004-000
O-Ring
5
935-005-000
Edge protection
7
935-007-000
Cap assembly (8,9)
8
935-008-000
Cap
9
935-009-000
Gasket
10
935-010-000
Fuel tank
12
935-012-000
Carburetor cover
13
935-013-000
Gasket
15
935-015-000
O-Ring
16
935-016-000
Regulating needle assembly (17,18)
17
935-017-000
Regulating needle
18
935-018-000
O-Ring
19 #
935-019-000
Atomizer nozzle assembly (20,22) AR35
19 #
909-019-000
Atomizer nozzle assembly (20,22) AE9
20 #
935-020-000
Atomizer nozzle AR35
20 #
909-020-000
Atomizer nozzle AE9
21
935-021-000
O-Ring
22
935-022-000
O-Ring
23 #
935-023-000
Carburetor (24,25x2), AR35
23 #
909-023-000
Carburetor (24,25x2), AE9
23/1 #
935-023-010
Carburetor cpl. AR35
23/1 #
909-023-010
Carburetor cpl. AE9
23/2 #
935-023-020
Carburetor assembly AR35
23/2 #
909-023-020
Carburetor assembly AE9
24 #
935-024-000
Carburetor housing AR35
24 #
909-024-000
Carburetor housing AE9
25
935-025-000
Set screw, M6x20
26 #
935-026-000
Swirl vane AR35
26 #
909-026-000
Swirl vane AE9
27 #
935-027-000
O-Ring AR35
27 #
909-027-000
O-Ring AE9
27/1
935-027-010
O-Ring
29
935-029-000
O-Ring
30 #
935-030-000
Air intake valve assembly AR35 (32-34,34/1,60,61,63)
30 #
909-030-000
Air intake valve assembly AE9 (32-34,34/1,60,61,63)
31
935-031-000
Fill head screw M5x6
32
935-032-000
Spacer plate
33
935-033-000
Diaphragm
34
935-034-000
Valve body
