General Information
3-10 Flying Cloud
25-ft. Model
1
5
4
3
2
1. Lavatory Drain
2. Black WaterTank (Toilet)
3. Galley Drain
4. Gray Water Tank
5. Shower Drain
25FB-ft. Model
3
4
2
1
1. Lavatory Drain
2. Black WaterTank (Toilet)
3. Galley Drain
4. Gray Water Tank
27FB-ft. Model
1
2
3
4
1. Lavatory Drain
2. Black WaterTank (Toilet)
3. Galley Drain
4. Gray Water Tank
28-ft. Model
1
2
4
3
1. Lavatory Drain
2. Black WaterTank (Toilet)
3. Galley Drain
4. Gray Water Tank
