Airstream Basecamp 2017 - Dinette Tables; Galley; Lounge; Shower Stall

Interior
5-4 2017 Basecamp
Dinette Tables
The dinette tables can be removed and stored to make
room to use the rear access door� The table top is
removed by pulling straight up on the table top� The
Legs can be removed by depressing the black buttons
on each of the oor sockets and rotating the table
legs� The table tops can be stored on the face of the
curbside dinette seat via bungee cords, while the legs
can be attached to the underside of the dinette seat
hatch�
Lounge
The dinette seats and tables have been designed to
convert into a bed� The dinette tables will need to be
lowered into position by installing a set of smaller legs
which are located on the underside of the curbside
dinette seat hatch� The longer legs can now be stored
in this same location� Once the tables are lowered into
position each dinette seats top can be unfolded to lay
across the table tops� The dinette seat back cushions
will be laid between the two seat cushions to ll in the
middle of the bed�
Shower Stall
To clean your berglass shower stall unit, use warm
water and one of the stronger liquid detergents� Do not
use abrasive cleaners as they may scratch and dull the
surface of your unit� Stubborn stains can be removed
with solvents such as turpentine, paint thinner, or
acetone� Restore dulled areas by rubbing with an
automotive type liquid cleaner, then, put the soft glow
back into your unit with a light application of liquid wax�
CAUTION
Applying wax to the base of the shower oor is
not recommended, as this could create an unsafe
surface.
Telephone Shower Head
The telephone shower head is designed to give
maximum exibility in usage, and provides for water-
saving techniques when using your trailer on self-
containment� It can be held in the hand and moved
about the body� Normally, the best water conservation
procedure is to wet the entire body then turn the water
off� Apply soap, lather thoroughly, and then rinse the
soap off� The shower stall is equipped with an exterior
shower door that allows the shower head to be passed
through to the outside� Make sure the door remains
locked when not in use�
Galley
The Basecamp galley has two retractable 120V
receptacles with USB ports installed in the galley’s
counter top. These ush mounted receptacles can be
pulled up to use the outlets/USB ports� When not in
use, simply press the receptacles back down to lock
them in place� The receptacle is completely self-
contained and sealed should any spillage occur around
its casing�
