Exterior
6-6 2017 Basecamp
Hitch/Coupler
1� Open Position
2� Padlock Insert Hole
3� Closed Position
Operating Instructions
1� To open - slide forward and pull up to open latch
before inserting ball�
2� Place coupler on ball of same diameter as coupler
and of same or greater capacity�
3� When ball is completely nested in socket, push
top of latch handle rearward until handle snaps
into closed position� Extend jack to ground and lift
tow vehicle/trailer combination 2 to 4 in� to ensure
coupler is securely attached to tow ball� Retract
jack before towing�
4� Insert padlock through hole in handle for theft-
prevention purposes�
WARNING
Always open latch handle before inserting ball into
coupler.
Liquid Petroleum Gas (LPG)
Fill Valve
The LPG tanks are equipped with ll valve connections
RV Type I Acme� The large, green, nylon swivel nut is
a right-hand thread and is designed for hand operation
only�
The valve features an internal spring-loaded module
that will not allow gas to ow from the cylinder until a
positive seal has been made at the connection� The
valve outlet has 1-5/16 in� Acme threads on the outlet
exterior, and female POL, left-handed threads on its
interior� This feature allows for connection of the new
wrenchless, right-handed, Acme RV connection while
still accommodating the standard left-handed POL
ttings used for lling propane cylinders.
The mating, green swivel nut and brass nipple also
incorporate new features: the green nylon nut swivels
on a black bushing that is heat-sensitive� Between 240
and 300°F, the bushing will yield (melt) allowing the
spring-loaded module in the valve to push the brass
nipple back (approximately 1/4 in�), closing the module
and stopping the ow of gas from the cylinder. Inside
the brass nipple is a ow-limiting device designed
to sense excessive gas ow. If an excessive ow is
sensed, the ow-limiting device shuts the ow down
to a maximum of 10 SCFH (Standard Cubic Feet per
Hour) or less� This is also referred to as the bypass
ow.
