1 Gear Box Housing (NEW) 1 46 fitting for vents 2 131 Name Plate 1
2 Gear Box Cover (rear) 1 47 Locking Disk, Front 2 132 Lable, Hot 1
3 Pump Housing 1 51 Silencer Ass'y Flange 1 133 Lable, read manul 1
4 Pump Housing Cover 1 (End Plate) 1 52 Gasket, Silencer Ass'y 1 139 NPT Adapter 3" (NEMA Only) 2
5 Pump Housing Cover 2 (End Plate) 1 59 Silencer assembly 1 156 Elbow 1_1/2" 1
6 Fan Housing 1 60
Upper Housing (Threaded), G 3"
1 201 Hex. Socket Head Cap Screw / M6 x 15 8
7 Pump Housing Cover (front) 1 61
Inlet screen (Conical )
1 202 Hex. Socket Head Cap Screw / M6 x 30 8
11 Shaft 1 1 68
Connection Housing
1 203 Hex. Socket Head Cap Screw / M6 x 15 2
12 Shaft 2 1 69 Gasket, Connection Housing 2 204 Hex. Socket Head Cap Screw / M12 x25 1
13 Gear 1 1 70 Flange Adapter 1 205 Hex. Socket Head Cap Screw / M5 x 8 2
14 Gear 2 1 71 Gasket, Flange Adapter 2 206 Hex. Socket Head Cap Screw / M12 x25 2
15 Rotor 1 1 80 Pipe, for Oil sight glass 2 207 Stud Bolt / M12 x 275 / 290 8
16 Rotor 2 1 81 Gasket, Oil Sight Glass 4 208 Hexagon Nut / M12 8
17 Spacer 2 82 Plate 1 209 Washer, Spring Lock, 12mm 8
17-1 Spacer 2 83 Oil Sight Glass 1 210 Hex. Socket Head Cap Screw / M12 x 25 1
18 Piston Ring 8 84 Plug for oil Sight Glass 1 211 Hexagon Bolt / M12 x 35 4
19 Sleeve 4 85 Pipe, for Drain Plug 2 212 Washer, Spring Lock, 12mm 4
20 O-Ring 4 86 Gasket, Drain Plug 4 214 Hexagon Bolt (NEMA only) 4
21 Shaft Seal 4 87 Drain Plug 2 215 Set Screw / M8 x 15 2
22 Bearing, 2 88 Oil filler Breather, Plastic 1 216 Set Screw / M8 x 15 2
23 Bearing cover 2 89 O-Ring for Oil filler, for PN 100.088.00 1 217 Round Head Bolt / M5 x 12 5
24 Key, for Rotor 2 90 Foot Mount, Right 1 218 Hex. Socket Head Cap Screw / M10 x 60 6
25 Key, for Gear 1 91 Foot Mount, Left 1 219 Washer, Spring Lock, 10mm 6
26 Key, for Coupling 1 92 Shield Cover, Bottom 1 231 Hex. Socket Head Cap Screw / M12 x 25 4
27 Sleeve 2 93 Accoustic Mat for Shield Cover, Bottom 1 232 Hex. Socket Head Cap Screw / M8 x 160 4
28 Power Lock 1 94 Shield Cover, Side, (NEW GB) 1 233 Hex. Socket Head Cap Screw / M8 x 20 4
29 Wahser, Spring 2 95 Shield Cover, Front 1 247 Hex. Socket Head Cap Screw / M6 x 20 6
30 Flinger 1 96 Accoustic Mat for Shield Cover, Front & Side 1 261 Hex. Socket Head Cap Screw / M12 x 25 6
31 Sleeve, 1 97 Foot, Rubber 4 263 Set Screw / M12 x 30 4
32 Roller Bearing 2 98 Cover, Plastic Foot Mount 4 264 Hexagon Nut / M12 4
33 Locking Disk 1 99 Grill for Fan 2 265 Hex. Socket Head Cap Screw / M12 x 140 2
34 O-Ring 1 100 Coupling, Pump Side 1 266 Washer, Spring Lock, 12mm 2
35 Sleeve, 1 101 Insert, Coupling 1 267 Round Head Bolt/ M5 x 10 4
36 Shaft Seal, 1 102 Coupling, Motor Side 1 268 Round Head Bolt / M5 x 10 4
37 O-Ring, Compressor cover, 2 103 Fan, New, Plastic 1 291 Round Head Bolt / M5 x 10 12
38 O-Ring, Gear Box cover, 1 105 Flange Adapter set (NEMA only) 1 292 Washer, Flat, 5mm 12
39 Dowel Pin 12 110 Motor 1 573 Washer, Spring Lock, 10mm 4
40 Locking Disk 1 120 Regulator 1 577 Hexagon Nut M10 (vcx only) 4
41 O-ring, Bearing cover 2 121 Silencer, Inlet 1_1/2" 1 729 Hex. Socket Head Cap Screw / M10 x 20 4
42 Cover, Roller Bearing 2 123 Pipe, extension, medium, Inlet, 1_1/2" 1 750 Stud M10 x 40 4
43 Nipple set, grease 2 128 Pipe, extension, shor, Inlet, 1_1/2" 1 945 Pipe 3" Short (IEC only) 1
44 O-Ring 2 129 Eye Bolt 1
45 Spacer Ring, Roller Bearing 2 130 Label, Direction Arrow 1
VCX 400B / 505B PART LIST
Pos.# Qty.Description Pos.# Qty.Description Pos.# Qty.Description
To Next Page
