1 Gear Box Housing (NEW) 1 60 Inlet flange, Upper Housing 1 130 Label, Direction Arrow 1
2 Gear Box Cover (rear) 1 61 Inlet screen (Conical ) 1 131 Name Plate 1
3 Pump Housing 1 62 O-Ring, Inlet Flange, low and upper part 2 132 Lable, Hot 1
4 Pump Housing Cover 1 (End Plate) 1 63 Inlet flange, Lower housing 1 133 Lable, read manual 1
6 Fan Housing 1 64 O-Ring, Check valve plate 1 141 Bushing 2" x 1_1/4" 1
11 Shaft 1 1 65 Check valve plate 1 154 Pipe, extension, inlet 1_1/2" 1
12 Shaft 2 1 66 Spring, Check valve 1 201 Hex. Socket Head Cap Screw / M6 x 15 8
13 Gear 1 1 67 Check valve guide 1 202 Hex. Socket Head Cap Screw / M6 x 25 6
14 Gear 2 1 69 Gasket, Inlet Connection Housing 1 203 Hex. Socket Head Cap Screw / M4 x 12 2
15 Rotor 1 1 70 Flange Adapter, Inlet 1 204 Hex. Socket Head Cap Screw / M8 x 25 1
16 Rotor 2 1 71 Gasket, Flange 2 205 Hex. Socket Head Cap Screw / M5 x 8 2
17 Spacer 2 80 Pipe, for Oil sight glass 2 206 Hex. Socket Head Cap Screw / M8 x 25 2
18 Piston Ring 4 81 Gasket, Oil Sight Glass 4 207 Hex. Socket Head Cap Screw / M10 x 100(100), 120(150) 8
19 Sleeve 2 82 Plate 1 209 Washer, Spring Lock, 10mm 8
20 O-Ring 2 83 Oil Sight Glass 1 210 Hex. Socket Head Cap Screw / M8 x 25 1
21 Shaft Seal, 2 84 Plug for oil Sight Glass 1 211 Hexagon Bolt / M12 x 35 4
22 Bearing, 2 85 Pipe, for Drain Pulg 2 212 Washer, Spring Lock, 12mm 4
23 Bearing cover 2 86 O-ring, Drain Plug 4 213 Hexagon Bolt / M12 x 25 (NEMA only) 4
24 Key, for Rotor 2 87 Drain Plug 2 214 Hexagon Bolt / M12 x 25(IEC) / (NEMA) 4
25 Key, for Gear 1 88 Oil filler Breather, Plastic 1 215 Set Screw / M8 x 10 2
26 Key, for Coupling 1 89 O-Ring for Oil filler 1 216 Set Screw / M8 x 10 2
27 Sleeve 1 90 Foot Mount, Right 1 217 Round Head Bolt / M5 x 12 5
28 Power Lock 1 91 Foot Mount, Left 1 218 Hex. Socket Head Cap Screw / M10 x 60 6
29 Washer, Spring Lock, 6mm 2 92 Shield Cover, Bottom 1 219 Washer, Spring Lock, 10mm 6
30 Flinger 1 93 Accoustic Mat for Shield Cover, Bottom 1 231 Hex. Socket Head Cap Screw / M8 x 20 8
31 Sleeve 2 94 Shield Cover, Side, with mat (NEW GB) 1 232 Hex. Socket Head Cap Screw / M6 x 80 4
32 Bearing, 2 95 Shield Cover, Front with mat 1 243 Stud / M8 x 40 4
33 Locking Disk 3 96 Accoustic Mat for Shield Cover, front and Side 1 244 Washer, Spring Lock, 8mm 4
34 O-Ring 1 97 Foot, Rubber, 30x20xM8 4 261 Hex. Socket Head Cap Screw / M10 x 15 6
35 Sleeve 1 98 Cover, Plastic Foot Mount 4 263 Set Screw / M8 x 20 4
36 Shaft Seal, 1 99 Grill for Fan 2 264 Hexagon Nut / M8 4
37 O-Ring, Compressor cover 2 100 Coupling, Pump Side 1 265 Hex. Socket Head Cap Screw / M10 x 110 2
38 O-Ring, Gear Box cover 1 101 Insert, Coupling 1 266 Washer, Spring Lock, 10mm 2
39 Dowel Pin 8 102 Coupling, Motor Side 1 267 Round Head Bolt/ M5 x 10 4
40 Locking Disk 1 103 Fan, new, Plastic 1 268 Round Head Bolt / M5 x 10 4
51 flange, Exhaust Silencer 1 105 Flange Adapter 1 291 Round Head Bolt / M5 x 10 12
52 Gasket, Exhaust Silencer 1 110 Motor
1
292 Washer, Flat, 5mm 12
58 Inlet Connection Housing 1 120 Vacuum Regulator 1 574 Hexagon Nut M8 4
59 Silencer assembly 1 129 Eye Bolt 1
VCX 100B / 150B PART LIST
Pos. # Description QtyPos. #Pos. # DescriptionDescription QtyQty
