Component identification
.
1
Left side cover
2
Front cover
3
Oil vessel support
4
Front wheel (big)
5
Compressor ventilation
fan
6
Compressor
7
Vacuum pump
8
Main manifold module
( solenoids, pipelines
and oil separators)
9
Rear wheels (small)
10
Refrigerant storage
tank
11
Condenser and
ventilation fan
12
Right cover
13
Rear cover
14
PCA board
15
Touch screen
16
Manometers
17
Control panel cover
18
Refrigerant flow vision
window
