19
DAV009, DAV012
Installation Procedures
3.Relationship between locations of the unit and the hoisting studs (unit: mm).
a b c d e f gmodel ih
4831002 136 1105 255 880105 220970
DAV009/DAV012 538418 483 220 255 610508 !136
DAV016
DAV009, DAV016
1.The indoor units of this series are low static pressure air conditioners.
2.The indoor units should be installed with an inspection hole for maintenance.
Cautions for Installation
Standard Style(given in Factory)
Yellow
Black
Blue
Red
Yellow
Orange
Black
Blue
Yellow
Black
Red
Blue
Yellow
Black
Red
Blue
High Wind Speed Style
Static pressure range Unit: Pa
Standard static pressure
Maximal static pressure
0
20
Selection of fan rotated speed
The fan is mounted with red down-lead end and red down-lead end. The standard model was
set when the machine was made in the factory. The red down-lead end with high speed can be
used when the filter with high performance is used to make static pressure ascend. The connected
style is shown in Fig.3.
H
J
K
F
L
