2. PRODUCT DATA SHEET
2.1 AWSI-DED076-N11 / AWAU-YED076-H13
Model Indoor Unit
AWSI-DED076-N11
Model Outdoor Unit
AWAU-YED076-H13
Installation Method of Pipe
Soldering
Characteristics
Units
Cooling
Heating
Capacity
(1)
kW
22.4
25.0
Power input
kW
6.7
6.54
SEER /SCOP
(2)
W/W
3.34
3.82
Energy efficiency class
A
A
Power supply
V/Ph/Hz
380-415V/3N~/50Hz
Circuit breaker rating
A
20
INDOOR
Fan type & quantity
Centrifugal x 2
Fan speeds
H/M/L/VL
RPM
-
Air flow
(3)
H/M/L/VL
m3/hr
4000
External static pressure
Min-Max
Pa
150(0-200)
Sound power level
(4)
H/M/L
dB(A)
64
Sound pressure level
(5)
H/M/L/VL
dB(A)
54
Moisture removal
l/hr
7.5
Condensate drain tube O.D / I.D
mm
OD30 (ID 28.5)
Dimensions
WxHxD
mm
1483x385x791
Weight
kg
82
Package dimensions
WxHxD
mm
1578x472x883
Packaged weight
kg
104
Stacking height
units
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter QXAS-D32zX050 x 2
Fan type & quantity
Axial x 2
Fan speeds
H/L
RPM
820
Air flow
H/L
m3/hr
9000
Sound power level
(4)
H/L
dB(A)
70
Sound pressure level
(5)
H/L
dB(A)
60
Dimensions
WxHxD
mm
1098x1584x399
Weight
kg
175
Package dimensions
WxHxD
mm
1183x1785x505
Packaged weight
kg
180
Stacking height
Units
1
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
7.2
Additional charge per 1 meter
gr / 1m
20
Connections between units
Liquid line
In.(mm)
3/8”
Suction line
In.(mm)
7/8”
Max.tubing length
m.
120
Max.height difference
m.
13
Operation control type
Wired Remote control
