PRODUCT DATA SHEET
SM HDDHED 1-A.1 GB
2.2 HDD012 / HED012 // YDD 012
Model Indoor Unit
HDD/HED012
Model Outdoor Unit
YDD 012
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(4)
kW 3.53(0.6-3.96) 4.1(0.6-5.13)
Power input
(4)
kW 1.1(0.22-1.45) 1.14(0.22-1.55)
EER (Cooling) or COP(Heating)
(4)
W/W 3.21 3.61
Energy efficiency class A A
Power supply
V 220-240
Ph 1
Hz 50
Rated current A 6.5 7.8
Power factor 0.97 0.97
Prated (IDU+ODU) W 1650
Starting current A
Circuit breaker rating A 16
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds
Cooling SH/H/M/L RPM 1350/1150/950/750
Heating SH/H/M/L RPM 1350/1190/1020/850
Air flow
(1)
SH/H/M/L m3/hr 680/560/410/330
External static pressure Min Pa 0
Sound power level
(2)
SH/H/M/L dB(A) 52/47/41/35
Sound pressure level
(3)
SH/H/M/L dB(A) 42/37/31/25
Moisture removal l/hr 1.5
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 770x283x201
Net Weight kg 9
Package dimensions WxHxD mm 844x342x261
Packaged weight kg 12
OUTDOOR
Refrigerant control Capillary
Compressor type, model Rotary,Daikin 1YC23AEXD
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 930
Air flow H m3/hr 1600
Sound power level H dB(A) 58
Sound pressure level
(3)
H dB(A) 48
Dimensions WxHxD mm 658x550x275
Net Weight kg 30
Package dimensions WxHxD mm 771x592x348
Packaged weight kg 34
Refrigerant type R410A
Standard charge kg(5m) 1
Additional charge 15g/m(5m<L<15m)
Connections
between units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 3/8"(9.53)
Max.tubing length m. Max. 15
Max.height difference m. Max. 5
Operation control type Remote control
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
