EXPLODED VIEW & SPARE PART LIST
14-28 SM YIF 2-A.1 GB
14.22 Spare part list of Indoor Unit CAF018
NO. Part Code Part Description qty
1 30297301 Display Board Z7A351 1
2 10312702 Centrifugal Fan 1
3 15012707 Fan Motor 1
4 01029408 Evaporator Assy 1
5 01702702 Motor Mounting Rack 1
9 01382719 Tube Exit Plate Assy 1
10 01399408 Electric Box Assy 1
11 42010258 Terminal Board 1
12 43110233 Transformer 48X26G 1
13 33010026 Capacitor CBB61 1
14 30227110 Main PCB Z71351D 1
15 01412723 Electric Box Cover 1
18 390000592 Tube Sensor 1
20 450127011 Water Level Switch 1
22 43130320 Water Pump 1
23 39000191 Ambient Temperature Sensor 1
To Next Page
