What to do if the compressor of my Airwell GC 18 DCI does not start?
If the compressor of your Airwell Heat Pump doesn't start, it may be due to an electronics control problem or protection issue. You should perform diagnostics as described in section 11.3 of the manual and follow the recommended actions.
Why is my Airwell Heat Pump not responding to the remote control?
If your Airwell Heat Pump unit isn't responding to the remote control, the remote control message may not be reaching the indoor unit. First, check the remote control batteries. If the batteries are fine, inspect the display and display wiring. If those are OK, replace the display PCB. If the unit still doesn't respond, replace the controller.
What to do if the compressor of my Airwell Heat Pump stops during operation?
If the compressor in your Airwell Heat Pump stops during operation but the green LED remains on, it could be due to an electronic control or power supply problem. You should perform diagnostics as described in section 11.3 of the manual and follow the recommended actions.
Why is the indoor fan of my Airwell Heat Pump not starting?
If the indoor fan of your Airwell Heat Pump doesn't start, but the louvers are open and the green LED is lit, there could be a few reasons: * If the unit is in heat mode, the coil might not be warm yet. Try changing to cool mode to test. * There might be a problem with the PCB or capacitor. Switch to high speed and check if the power supply to the motor is higher than 130VAC (for triack controlled motor) or higher than 220VAC for fixed speed motors. If it is, replace the capacitor. If not, replace the controller.
What to do if Airwell GC 18 DCI Heat Pump responds to remote but the Green LED doesn't light up?
If your Airwell Heat Pump responds to the remote control message but the Operate indicator (Green LED) doesn't light up, there may be a problem with the display PCB. Replace the display PCB. If the issue persists, replace the controller.
Why is the indoor fan of my Airwell Heat Pump working when the unit is off?
If the indoor fan of your Airwell Heat Pump is working when the unit is OFF, and the fan speed can't be changed with the remote, it indicates a PCB problem. Replace the controller.
How to fix a power supply indicator (Red LED) that does not light up on my Airwell GC 18 DCI?
If the power supply indicator (Red LED) on your Airwell Heat Pump doesn't light up, it indicates there's no power supply. Check the power supply. If the power supply is OK, check the display and display wiring. If those are OK, replace the controller.
General| Cooling Capacity | 5.3 kW |
|---|---|
| Heating Capacity | 5.6 kW |
| Refrigerant | R410A |
| Sound Pressure Level Indoor | 42 dB(A) |
| Sound Pressure Level Outdoor | 52 dB(A) |
| Outdoor Unit Weight | 35 kg |
| Type | Split System |
| EER | 3.2 |
| COP | 3.6 |
| Power Supply | 220-240V, 50Hz |
| Power Input Cooling | 1.6 kW |
| Energy Efficiency Ratio (EER) | 3.21 |
| Coefficient of Performance (COP) | 3.61 |
| Outdoor Unit Dimensions (HxWxD) | 540 x 780 x 250 mm |
Provides an overview of the PNX DCI INVERTER split wall mounted range and its models.
Highlights the key technological innovations and benefits of the PNX DCI series.
Describes the features and specifications of the indoor units, including display types and options.
Details the various types of air filters available for the PNX DCI series.
Explains the microprocessor indoor controller and infrared remote control system.
Describes the features and installation aspects of the outdoor units.
Information regarding flare type interconnecting tubing.
Lists available accessories for the units.
Specifies the documentation supplied with each unit.
Illustrates the compatibility between indoor and outdoor units.
Detailed technical specifications for the PNX 9 DCI model.
Detailed technical specifications for the PNX 12 DCI model.
Detailed technical specifications for the PNX 18 DCI model.
Detailed technical specifications for the PNX 21 DCI model.
Detailed technical specifications for the PNX 24 DCI model.
Defines the operational temperature and voltage limits for R410A refrigerant.
Provides detailed physical dimensions for PNX 9 and 12 DCI indoor units.
Provides detailed physical dimensions for GC 9, 12, and 18 DCI outdoor units.
Provides detailed physical dimensions for PNX 18, 21, and 24 DCI indoor units.
Provides detailed physical dimensions for the GC 21 DCI outdoor unit.
Provides detailed physical dimensions for the GC 24 Z DCI outdoor unit.
Cooling and heating capacity data, power input, and correction factors.
Cooling and heating capacity data, power input, and correction factors.
Cooling and heating capacity data, power input, and correction factors.
Cooling and heating capacity data, power input, and correction factors.
Cooling and heating capacity data, power input, and correction factors.
Adjustments to cooling and heating capacity based on tubing length.
Suction and discharge pressure curves vs. outdoor temperature.
General information regarding sound pressure measurements.
Octave band sound pressure level spectra for indoor units PNX 9, 12, 18, 21, 24.
Octave band sound pressure level spectra for outdoor units GC 9, 12, 18, 21, 24 Z DCI.
Details power supply, current ratings, circuit breaker, and cable specifications.
Wiring diagrams for PNX 9/12 indoor and GC 9/12 outdoor units.
Wiring diagrams specific to PNX 18 and 21 DCI indoor units.
Wiring diagrams specific to GC 18 and 21 DCI outdoor units.
Wiring diagrams for PNX 24 DCI indoor and GC 24 DCI outdoor units.
Wiring diagrams specific to the GC 24 Z DCI outdoor unit.
Refrigeration cycle diagram for cooling mode.
Refrigeration cycle diagram for heating mode.
Refrigeration cycle diagrams for PNX 24 and GC 24 Z DCI models.
Illustrates electrical connections for PNX 9, 12, 18, 21 DCI units.
Illustrates electrical connections for the PNX 24 DCI unit.
Covers system operation concept, frequency control, and NLOAD settings.
Details fan modes, cool/heat/dry modes, and temperature compensation.
Covers defrost, overheating, deicing, and condensate overflow protections.
Information on unit controls, indicators, and jumper configurations.
Explains test mode operation and lists SW parameter tables.
Covers system operation concept, frequency control, and NLOAD settings.
Details compressor starting, fan control, EEV, RV, ionizer, and base heater.
Covers cool/heat/dry modes, temperature compensation, auto mode, and protections.
Explains test mode operation and lists SW parameter tables.
Addresses system failures, diagnostics, and MegaTool procedures.
Covers system failures and diagnostics specific to GC 24/30 DCI models.
Provides exploded views and parts lists for PNX 9, 12, 18, 21, 24 DCI indoor units.
Provides exploded views and parts lists for GC 9, 12, 18, 21, 24 Z DCI outdoor units.
Diagrams and torque values for flare nuts, valve caps, and service ports.
References related installation and operation manuals.
