7-1
ELECTRICAL DATA
SM PNXDCI 1-A.1 GB
7. ELECTRICAL DATA
7.1 Single Phase Unit
Model PNX 25 DCI PNX 35 DCI PNX 50 DCI PNX 60 DCI PNX 72 DCI
Power Supply 1 PH ,220-240VAC ,50HZ
Connected to To indoor To outdoor
Maximum Current 10A 13.5A 15A 15.7A
Inrush Current \
(a)
35A 45 A <35A
Starting Current\
(b)
10A 13.5 A 15A 15.7A
Circuit Breaker 16A 20 A
Power Supply 3 X 1.5 mm² 3 X 2.5 mm²
Interconnecting cable 4 X 1.5 mm² 4 X 2.5 mm²
(a) Inrush current is the current when power is up (charging the DC capacitors
at outdoor unit controller).
(b) Starting current is the current at compressor start up.
NOTE
Power wiring cord should comply with local lows and electrical
regulations requirements.
