EXPLODED VIEW & SPARE PART LIST
14-32 SM YIF 2-A.1 GB
14.26 Spare part list of Indoor Unit CAF042
NO. Part Code Part Description qty
1 01382715 Tube Exit Plate Assy 1
2 01332701 Major Mounting Plate 4
3 01302713 Front Side Plate 1
4 01302711 Left Side Plate Assy 1
5 01222701 Base Plate Assy 1
6 01302709 Rear Side Plate 1
7 01702701 Motor Mounting Rack 1
8 15012706 Fan Motor 1
9 10310101 Centrifugal Fan 1
10 01072732 Evaporator Linkage 1
11 390001921G Tube Sensor 1
12 01029405 Evaporator Assy 1
13 20182701 Water Tray Assy 1
14 01412721 Electric Box Base Plate 1
15 10372722 Flow Guide Loop 1
16 01399530 Electric Box Assy 1
17 42010258 Terminal Board 1
18 43110226 Transformer 1
19 20122054 Electric Box Cover Sub-Assy1 1
20 390001911 Ambient Temperature Sensor 1
21 20122055 Electric Box Cover Sub-Assy2 1
22 30227111 Main PCB Z71351E 1
23 33010012 Capacitor 1
24 01072707 Evaporator of Fixed Mount 2
25 10312701 Fan Fixer 1
26 01332751 Water Pump Assy 1
27 45010201 Water Level Switch 1
28 05230026 Drain Pipe for Water Pump 1
29 01302712 Right Side Plate Assy 1
30 01252713 Pump Backup Cover Plate Assy 1
31 30294219 Display Board 1
420101851 Terminal Board 1
05232702 Drain Hose Assy 1
05232044 Drain Hose 1
43130324 Water Pump 1
30510460 Remote controller YX1F1 1
