EXPLODED VIEW & SPARE PART LIST
14-34 SM YIF 2-A.1 GB
14.28 Spare part list of Indoor Unit CAF030
NO. Part Code Part Description qty
1 01382715 Tube Exit Plate Assy 1
2 01332701 Major Mounting Plate 4
3 01302718 Front Side Plate 1
4 01302715 Left Side Plate Assy 1
5 01222701 Base Plate Assy 1
6 01302714 Rear Side Plate 1
7 01702701 Motor Mounting Rack 1
8 15709404 Fan Motor 1
9 10312705 Centrifugal Fan 1
10 01074042 Connection Sheet Assy
11 390001921G Tube Sensor 1
12 01029415 Evaporator Assy 1
13 20182701 Water Tray Assy 1
14 01412721 Electric Box Base Plate
15 10372701 Flow Guide Loop 1
16 01399532 Electric Box Assy 1
17 42010258 Terminal Board 1
18 43110226 Transformer 1
19 20122054 Electric Box Cover Sub-Assy1 1
20 390001911 Ambient Temperature Sensor 1
21 30510460 Remote controller YX1F1 1
22 20122055 Electric Box Cover Sub-Assy2 1
23 30227111 Main PCB Z71351E 1
24 33010010 Capacitor CBB61 3.5kuF/450V 1
25 05232702 Drain Hose Assy 1
26 01072703 Evaporator of Fixed Mount 2
27 10312701 Fan Fixer 1
28 43130324 Water Pump 1
29 45010201 Water Level Switch 1
30 05230026 Drain Pipe for Water Pump 1
31 01302716 Right Side Plate 1
32 01252713 Pump Backup Cover Plate Assy 1
33 30294219 Display Board 1
