Airwell DAF009 - 2.22 CAF036; YIF036 T Product Data

PRODUCT DATASHEET
2-22 SM YIF 2-A.1 GB
2.22 CAF036 / YIF036T
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit CAF036
Model Outdoor Unit YIF036T
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Btu/hr 34120 37530
Capacity (4)
kW 10.0 11.0
Power input (4) kW 3.60 3.10
EER (Cooling) or COP(Heating) (4) W/W 2.77 3.54
Energy efficiency class
Power supply V/Ph/Hz 380-415V/3 Ph/50Hz
Rated current A 16.1 13.9
Starting current A
Circuit breaker rating (IDU/ODU) A 6/16
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 710/660/610
Air flow (1) H/M/L m3/hr 1660/1570/1500
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 63/61/58
Sound pressure level(3) H/M/L dB(A) 53/51/48
Moisture removal l/hr 2.9
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 840X320X840
Weight kg 38
Package dimensions WxHxD mm 960X394X960
Packaged weight kg 46
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Scroll
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 4000
Sound power level H/L dB(A) 70
Sound pressure level(3) H/L dB(A) 60
Dimensions WxHxD mm 1018x840x412
Weight kg 90
Package dimensions WxHxD mm 1110x985x450
Packaged weight kg 100
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 3.2/5
Additional charge per 1 meter g/m 120g/m
Liquid line In.(mm) 1/2"(12.7)
Suction line In.(mm) 3/4"(19.05)
Max.tubing length m. Max.50
OUTDOOR
Connections between units
Max.height m. Max.30
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal exte
r
nal static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
